دیتاشیت 550RC12M2230DGR
مشخصات دیتاشیت
| نام دیتاشیت |
SI550
|
| حجم فایل |
1164.16
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
RoHS:
true
-
Category:
Crystal Oscillator/Oscillator/Resonator/Voltage-Controlled Crystal Oscillators (VCXOs)
-
Datasheet:
SILICON LABS 550RC12M2230DGR
-
Frequency:
12.223MHz
-
Output Type:
LVPECL
-
Supply Current:
130mA
-
Supply Voltage:
2.5V
-
Frequency Stability:
±50ppm
-
Operating Temperature:
-40°C~+85°C
-
Package:
SMD7050-6P
-
Manufacturer:
SILICON LABS
-
Package / Case:
6-SMD, No Lead
-
Current - Supply (Disable) (Max):
75mA
-
Function:
Enable/Disable
-
Base Resonator:
Crystal
-
Spread Spectrum Bandwidth:
-
-
Absolute Pull Range (APR):
±125ppm
-
Mounting Type:
Surface Mount
-
Output:
LVPECL
-
Height - Seated (Max):
0.071" (1.80mm)
-
Current - Supply (Max):
130mA
-
Voltage - Supply:
2.5V
-
Size / Dimension:
0.276" L x 0.197" W (7.00mm x 5.00mm)
-
Ratings:
-
-
Part Status:
Active
-
Packaging:
Strip
-
Series:
Si550
-
Type:
VCXO
-
detail:
12.223MHz VCXO LVPECL Oscillator 2.5V Enable/Disable 6-SMD, No Lead
