دیتاشیت C8051F040-GQR
مشخصات دیتاشیت
| نام دیتاشیت |
C8051F040-47
|
| حجم فایل |
8621.993
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
320
|
مشخصات
-
RoHS:
true
-
CPU Core:
51Series
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
Watchdog:
Yes
-
ADC (Bit):
8bit;12bit
-
DAC (Bit):
10bit;12bit
-
Datasheet:
SILICON LABS C8051F040-GQR
-
CPU Maximum Speed:
25MHz
-
GPIO Ports Number:
64
-
Low-Voltage Detect:
Yes
-
Internal Oscillator:
Yes
-
Peripheral/Function:
Temperature transducer
-
Program Storage Size:
64KB
-
Universal Serial Bus:
-
-
Operating Voltage Range:
2.7V~3.6V
-
Operating Temperature Range:
-40°C~+85°C
-
Secure Digital Input and Output:
-
-
Package:
TQFP-100(14x14)
-
Manufacturer:
SILICON LABS
-
Peripherals:
Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
-
Number of I/O:
64
-
Oscillator Type:
Internal
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Speed:
25MHz
-
Connectivity:
CANbus, EBI/EMI, SMBus (2-Wire/I²C), SPI, UART/USART
-
EEPROM Size:
-
-
Package / Case:
100-TQFP
-
Program Memory Size:
64KB (64K x 8)
-
RAM Size:
4.25K x 8
-
Voltage - Supply (Vcc/Vdd):
2.7V ~ 3.6V
-
Base Part Number:
C8051F04
-
Supplier Device Package:
100-TQFP (14x14)
-
Core Size:
8-Bit
-
Series:
C8051F04x
-
Program Memory Type:
FLASH
-
Data Converters:
A/D 8x8b, 13x12b; D/A 2x10b, 2x12b
-
Mounting Type:
Surface Mount
-
Core Processor:
8051
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Not For New Designs
-
detail:
8051 C8051F04x Microcontroller IC 8-Bit 25MHz 64KB (64K x 8) FLASH 100-TQFP (14x14)
