دیتاشیت MMBTA05LT1G
مشخصات دیتاشیت
| نام دیتاشیت |
MMBTA05L,06L
|
| حجم فایل |
100.759
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi MMBTA05LT1G
-
Transistor Type:
NPN
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Collector Current (Ic):
500mA
-
Power Dissipation (Pd):
225mW
-
Transition Frequency (fT):
100MHz
-
DC Current Gain (hFE@Ic,Vce):
100@100mA,1V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
60V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
250mV@100mA,10mA
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
500mA
-
Voltage - Collector Emitter Breakdown (Max):
60V
-
Vce Saturation (Max) @ Ib, Ic:
250mV @ 10mA, 100mA
-
Current - Collector Cutoff (Max):
100nA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
100 @ 100mA, 1V
-
Power - Max:
225mW
-
Frequency - Transition:
100MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
MMBTA05
-
detail:
Bipolar (BJT) Transistor NPN 60V 500mA 100MHz 225mW Surface Mount SOT-23-3 (TO-236)
