دیتاشیت MMBZ27VCLT1G
مشخصات دیتاشیت
| نام دیتاشیت | MMBZxxVxL, SZMMBZxxVxL Series |
|---|---|
| حجم فایل | 64.499 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت MMBZxxVxL, SZMMBZxxVxL Series |
MMBZxxVxL, SZMMBZxxVxL Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: onsemi MMBZ27VCLT1G
- Breakdown Voltage: 25.65V
- Bidirectional Channels: 1
- Unidirectional Channels: 2
- Maximum Clamping Voltage: 38V
- Reverse Stand-Off Voltage (Vrwm): 22V
- Peak Pulse Current (Ipp)@10/1000us: 1A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 40W
- Package: SOT-23(TO-236)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Type: Zener
- Voltage - Reverse Standoff (Typ): 22V
- Voltage - Breakdown (Min): 25.65V
- Voltage - Clamping (Max) @ Ipp: 38V
- Current - Peak Pulse (10/1000µs): 1A
- Power - Peak Pulse: 40W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Base Part Number: MMBZ27
- detail: 38V Clamp 1A Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
