دیتاشیت NANO112SB1AN
مشخصات دیتاشیت
| نام دیتاشیت | Nano102, Nano112 Series |
|---|---|
| حجم فایل | 3380.111 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 100 |
دانلود دیتاشیت Nano102, Nano112 Series |
Nano102, Nano112 Series Datasheet |
|---|
مشخصات
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 4KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- PWM (Bit): -
- 8Bit Timer: -
- LCD Module: Yes
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 58
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: LCD/LED Driver;DMA;WDT;LIN(Local Interconnect Network);IrDA
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 16KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-64(7x7)
- Manufacturer: Nuvoton Tech
- Series: NuMicro™ Nano112
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M0
- Core Size: 32-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, LINbus, SmartCard, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
- Number of I/O: 58
- Program Memory Size: 16KB (16K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Data Converters: A/D 7x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 64-LQFP
- Supplier Device Package: 64-LQFP (7x7)
- detail: ARM® Cortex®-M0 NuMicro™ Nano112 Microcontroller IC 32-Bit 32MHz 16KB (16K x 8) FLASH 64-LQFP (7x7)
