2SA2029M3T5G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت 2SA2029M3T5G	دانلود دیتاشیت

RoHS: true
Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
Datasheet: onsemi 2SA2029M3T5G
Transistor Type: PNP
Collector Current (Ic): 100mA
Power Dissipation (Pd): 265mW
Transition Frequency (fT): 140MHz
DC Current Gain (hFE@Ic,Vce): 120@1mA,6V
Collector Cut-Off Current (Icbo): 500pA
Collector-Emitter Breakdown Voltage (Vceo): 50V
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 500mV@5mA,50mA
Package: SOT-723
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Current - Collector (Ic) (Max): 100mA
Voltage - Collector Emitter Breakdown (Max): 50V
Vce Saturation (Max) @ Ib, Ic: 500mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 500pA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 1mA, 6V
Power - Max: 265mW
Frequency - Transition: 140MHz
Operating Temperature: 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: SOT-723
Supplier Device Package: SOT-723
Base Part Number: 2SA2029
detail: Bipolar (BJT) Transistor PNP 50V 100mA 140MHz 265mW Surface Mount SOT-723
