NUC123LD4AN0 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NUC123LD4AN0 |
|---|---|
| حجم فایل | 44.975 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 99 |
دانلود دیتاشیت NUC123LD4AN0 |
دانلود دیتاشیت |
|---|
سایر مستندات
NUC123 Datasheet 99 pages
NUC123 Prod. Brief 37 pages
مشخصات فنی
- CAN: -
- I2C: 2
- I2S: 1
- SPI: 3
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 20KB
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Nuvoton Tech NUC123LD4AN0
- PWM (Bit): 12bit
- 8Bit Timer: -
- UART/USART: 2
- 16Bit Timer: -
- 32Bit Timer: 4
- Real-Time Clock: -
- CPU Maximum Speed: 72MHz
- GPIO Ports Number: 36
- Low-Voltage Detect: Yes
- CCP Capture/Compare: Yes
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: Low-VoltageDetect;DMA;CCP capture/compare;IrDA;WDT
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 68KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 2.5V~5.5V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-48(7x7)
- Manufacturer: Nuvoton Tech
- Series: NuMicro™ NUC123
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M0
- Core Size: 32-Bit
- Speed: 72MHz
- Connectivity: I²C, IrDA, SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LVD, POR, PS2, PWM, WDT
- Number of I/O: 36
- Program Memory Size: 68KB (68K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2.5V ~ 5.5V
- Data Converters: A/D 8x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-LQFP
- detail: ARM® Cortex®-M0 NuMicro™ NUC123 Microcontroller IC 32-Bit 72MHz 68KB (68K x 8) FLASH
