MMBD6100LT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MMBD6100LT1G
|
|
حجم فایل
|
91.725
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
3
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Diodes - General Purpose
-
Datasheet:
onsemi MMBD6100LT1G
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
70V
-
Forward Voltage (Vf@If):
1.1V@100mA
-
Reverse Leakage Current:
100nA@50V
-
Average Rectified Current (Io):
200mA
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
70V
-
Current - Average Rectified (Io) (per Diode):
200mA (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1.1V @ 100mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Reverse Recovery Time (trr):
4ns
-
Current - Reverse Leakage @ Vr:
100nA @ 50V
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
MMBD61
-
detail:
Diode Array 1 Pair Common Cathode Standard 70V 200mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3
