ESD9X12ST5G دیتاشیت

ESD9X12ST5G

مشخصات دیتاشیت

نام دیتاشیت ESD9X12ST5G
حجم فایل 98.803 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت ESD9X12ST5G

دانلود دیتاشیت

سایر مستندات

ESD9X3.3ST5G, SZESD9X3.3ST5G Series 6 pages

ESD9X12ST5G 4 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: TECH PUBLIC ESD9X12ST5G
  • Package: SOD-923
  • Manufacturer: TECH PUBLIC
  • Polarity: Unidirectional
  • Number of Lines: 1
  • Clamping Voltage@Ipp: 23.7V
  • Breakdown Voltage (VBR): 13.5V
  • Peak Pulse Current(Ipp)@8/20us: 5.9A
  • Reverse Stand-Off Voltage (Vrwm): 12V
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 12V (Max)
  • Voltage - Breakdown (Min): 13.5V
  • Voltage - Clamping (Max) @ Ipp: 23.7V
  • Current - Peak Pulse (10/1000µs): 5.9A (8/20µs)
  • Power - Peak Pulse: 140W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 30pF @ 1MHz
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: SOD-923
  • Supplier Device Package: SOD-923
  • Base Part Number: ESD9
  • detail: 23.7V Clamp 5.9A (8/20µs) Ipp Tvs Diode Surface Mount SOD-923
