دیتاشیت M74VHC1GT04DFT1G

MC74VHC1GT04 Series

مشخصات دیتاشیت

نام دیتاشیت MC74VHC1GT04 Series
حجم فایل 76.989 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت MC74VHC1GT04 Series

MC74VHC1GT04 Series Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Inverters
  • Datasheet: onsemi M74VHC1GT04DFT1G
  • Package: SC-88A
  • Manufacturer: onsemi
  • Series: 74VHC
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: Inverter
  • Number of Circuits: 1
  • Number of Inputs: 1
  • Features: -
  • Voltage - Supply: 3V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: 0.53V ~ 0.8V
  • Logic Level - High: 1.4V ~ 2V
  • Max Propagation Delay @ V, Max CL: 7.7ns @ 5V, 50pF
  • Operating Temperature: -55°C ~ 125°C
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-88A (SC-70-5/SOT-353)
  • Package / Case: 5-TSSOP, SC-70-5, SOT-353
  • Base Part Number: M74VHC1
  • detail: Inverter IC 1 Channel SC-88A (SC-70-5/SOT-353)
