دیتاشیت BAV23CLT1G
مشخصات دیتاشیت
| نام دیتاشیت |
BAV23CLT1G
|
| حجم فایل |
109.834
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
onsemi BAV23CLT1G
-
Power Dissipation:
540mW
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
250V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.25V@200mA
-
Reverse Leakage Current:
100nA@200V
-
Reverse Recovery Time (trr):
150ns
-
Average Rectified Current (Io):
400mA
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
250V
-
Current - Average Rectified (Io) (per Diode):
400mA
-
Voltage - Forward (Vf) (Max) @ If:
1.25V @ 200mA
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
100nA @ 200V
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
BAV23
-
detail:
Diode Array 1 Pair Common Cathode Standard 250V 400mA Surface Mount TO-236-3, SC-59, SOT-23-3
