NSR05F30NXT5G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSR05F30NXT5G
|
|
حجم فایل
|
80.553
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi NSR05F30NXT5G
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
30V
-
Forward Voltage (Vf@If):
400mV@500mA
-
Reverse Leakage Current (Ir):
75uA@30V
-
Average Rectified Current (Io):
500mA
-
Package:
DFN-2(0.6x1)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
30V
-
Current - Average Rectified (Io):
500mA (DC)
-
Voltage - Forward (Vf) (Max) @ If:
430mV @ 500mA
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
75µA @ 30V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
2-XDFN
-
Supplier Device Package:
2-DSN (1x.60)
-
Operating Temperature - Junction:
150°C (Max)
-
Base Part Number:
NSR05F
-
detail:
Diode Schottky 30V 500mA (DC) Surface Mount 2-DSN (1x.60)
