SBAV70WT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SBAV70WT1G
|
|
حجم فایل
|
81.588
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
onsemi SBAV70WT1G
-
Power Dissipation:
300mW
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
100V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.25V@150mA
-
Reverse Leakage Current:
1uA@100V
-
Reverse Recovery Time (trr):
6ns
-
Average Rectified Current (Io):
200mA
-
Package:
SOT-323(SC-70)
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io) (per Diode):
200mA (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1.25V @ 150mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Current - Reverse Leakage @ Vr:
1µA @ 100V
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-70, SOT-323
-
Supplier Device Package:
SC-70-3 (SOT323)
-
Base Part Number:
SBAV70
-
detail:
Diode Array 1 Pair Common Cathode Standard 100V 200mA (DC) Surface Mount SC-70, SOT-323
