SZMMBZ5V6ALT1G دیتاشیت

SZMMBZ5V6ALT1G

مشخصات دیتاشیت

نام دیتاشیت SZMMBZ5V6ALT1G
حجم فایل 85.126 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت SZMMBZ5V6ALT1G

دانلود دیتاشیت

سایر مستندات

MMBZ/SZMMBZyyyALT1 Series 8 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SZMMBZ5V6ALT1G
  • Number of Lines: 2
  • Clamping Voltage@Ipp: 8V
  • Breakdown Voltage (VBR): 5.32V
  • Reverse Stand-Off Voltage (Vrwm): 3V
  • Package: SOT-23(TO-236)
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 2
  • Bidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 3V
  • Voltage - Breakdown (Min): 5.32V
  • Voltage - Clamping (Max) @ Ipp: 8V
  • Current - Peak Pulse (10/1000µs): 3A
  • Power - Peak Pulse: 24W
  • Power Line Protection: No
  • Applications: Automotive
  • Capacitance @ Frequency: -
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3 (TO-236)
  • Base Part Number: SZMMBZ5V
  • detail: 8V Clamp 3A Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
