- دیتاشیت NUC029xAN, NUC029FAE
NUC029xAN, NUC029FAE دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NUC029xAN, NUC029FAE |
|---|---|
| حجم فایل | 1676.768 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 102 |
دانلود دیتاشیت NUC029xAN, NUC029FAE |
دانلود دیتاشیت |
|---|
سایر مستندات
NUC029TAN 102 pages
مشخصات فنی
- CAN: -
- I2C: 2
- I2S: -
- SPI: 1
- RoHS: true
- EEPROM: 4KB
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 4KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: Nuvoton Tech NUC029ZAN
- PWM (Bit): 16bit
- 8Bit Timer: -
- UART/USART: 2
- 16Bit Timer: -
- 32Bit Timer: 4
- Real-Time Clock: -
- CPU Maximum Speed: 50MHz
- GPIO Ports Number: 24
- Low-Voltage Detect: Yes
- CCP Capture/Compare: Yes
- Internal Comparator: Yes
- Internal Oscillator: Yes
- Peripheral/Function: Low-VoltageDetect;CCP capture/compare;IrDA;Multiplier;Divider;WDT;LIN(Local Interconnect Network)
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 64KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2.5V~5.5V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: QFN-32-EP(5x5)
- Manufacturer: Nuvoton Tech
- Series: NuMicro™ NUC029
- Part Status: Active
- Core Processor: ARM® Cortex®-M0
- Core Size: 32-Bit
- Speed: 72MHz
- Connectivity: I²C, IrDA, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, LVD, POR, PWM, WDT
- Number of I/O: 24
- Program Memory Size: 64KB (64K x 8)
- EEPROM Size: 4K x 8
- Voltage - Supply (Vcc/Vdd): 2.5V ~ 5.5V
- Data Converters: A/D 5x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 32-WFQFN Exposed Pad
- Supplier Device Package: 32-QFN (5x5)
- detail: ARM® Cortex®-M0 NuMicro™ NUC029 Microcontroller IC 32-Bit 72MHz 64KB (64K x 8) FLASH 32-QFN (5x5)
