- دیتاشیت BAV99RWT1G
BAV99RWT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | BAV99RWT1G |
|---|---|
| حجم فایل | 77.75 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت BAV99RWT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
BAV99WT1G Datasheet 4 pages
BAV99WT1, RWT1 Datasheet 4 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Switching Diode
- Datasheet: onsemi SBAV99WT1G
- Power Dissipation: 300mW
- Diode Configuration: Dual
- Reverse Voltage (Vr): 100V
- Operating Temperature: -65°C~+150°C@(Tj)
- Forward Voltage (Vf@If): 1.25V@150mA
- Reverse Leakage Current: 1uA@100V
- Reverse Recovery Time (trr): 6ns
- Average Rectified Current (Io): 215mA
- Package: SOT-323(SC-70)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 100V
- Current - Average Rectified (Io) (per Diode): 215mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.25V @ 150mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 2.5µA @ 70V
- Operating Temperature - Junction: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SC-70-3 (SOT323)
- Base Part Number: BAV99
- detail: Diode Array 1 Pair Series Connection Standard 100V 215mA (DC) Surface Mount SC-70, SOT-323
