دیتاشیت SS8550DTA
مشخصات دیتاشیت
| نام دیتاشیت |
SS8550
|
| حجم فایل |
246.209
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi SS8550DTA
-
Transistor Type:
PNP
-
Collector Current (Ic):
1.5A
-
Power Dissipation (Pd):
1W
-
Transition Frequency (fT):
200MHz
-
DC Current Gain (hFE@Ic,Vce):
160@100mA,1V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
25V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
500mV@80mA,800mA
-
Package:
TO-92-3
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
1.5A
-
Voltage - Collector Emitter Breakdown (Max):
25V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 80mA, 800mA
-
Current - Collector Cutoff (Max):
100nA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
160 @ 100mA, 1V
-
Power - Max:
1W
-
Frequency - Transition:
200MHz
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
SS8550
-
detail:
Bipolar (BJT) Transistor PNP 25V 1.5A 200MHz 1W Through Hole TO-92-3
