NUC126 Datasheet دیتاشیت

NUC126 Datasheet

مشخصات دیتاشیت

نام دیتاشیت NUC126 Datasheet
حجم فایل 2116.239 کیلوبایت
نوع فایل pdf
تعداد صفحات 140

دانلود دیتاشیت NUC126 Datasheet

دانلود دیتاشیت

سایر مستندات

NUC126 Series 148 pages

NUC126 Ref. Manual 943 pages

مشخصات فنی

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM Cortex-M0
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 20KB
  • Watchdog: -
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 72MHz
  • GPIO Ports Number: 49
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: DMA
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 256KB
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: 1.8V~5.5V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+105°C
  • Secure Digital Input and Output: -
  • Package: LQFP-64(7x7)
  • Manufacturer: Nuvoton Tech
  • Series: NuMicro™ NUC126
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: ARM® Cortex®-M0
  • Core Size: 32-Bit
  • Speed: 72MHz
  • Connectivity: I²C, SPI, UART/USART, USB
  • Peripherals: Brown-out Detect/Reset, DMA, I²S, LVR, PWM, RTC, UCID
  • Number of I/O: 49
  • Program Memory Size: 256KB (256K x 8)
  • EEPROM Size: 6K x 8
  • Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
  • Data Converters: A/D 15x12b
  • Oscillator Type: Internal/External
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 64-LQFP
  • Supplier Device Package: 64-LQFP (7x7)
  • detail: ARM® Cortex®-M0 NuMicro™ NUC126 Microcontroller IC 32-Bit 72MHz 256KB (256K x 8) FLASH 64-LQFP (7x7)
