NSR01L30MXT5G دیتاشیت

NSR01L30MXT5G

مشخصات دیتاشیت

نام دیتاشیت NSR01L30MXT5G
حجم فایل 66.515 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

مشاهده دیتاشیت NSR01L30MXT5G

دانلود دیتاشیت

سایر مستندات

NSR01L30MXT5G 4 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NSR01L30MXT5G
  • Reverse Voltage (Vr): 30V
  • Forward Voltage (Vf@If): 460mV@10mA
  • Reverse Leakage Current (Ir): 500nA@30V
  • Average Rectified Current (Io): 100mA
  • Package: DFN0603-2
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30V
  • Current - Average Rectified (Io): 100mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 460mV @ 10mA
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 500nA @ 30V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: 0201 (0603 Metric)
  • Supplier Device Package: 2-X3DFN (0.62x0.32)
  • Operating Temperature - Junction: 150°C (Max)
  • Base Part Number: NSR01L
  • detail: Diode Schottky 30V 100mA (DC) Surface Mount 2-X3DFN (0.62x0.32)
