M262ZIAAE دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | M262ZIAAE |
|---|---|
| حجم فایل | 44.9 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت M262ZIAAE |
دانلود دیتاشیت |
|---|
سایر مستندات
M261, M262, M263 24 pages
مشخصات فنی
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: 512KB
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 96KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: Nuvoton Tech M262ZIAAE
- PWM (Bit): -
- 8Bit Timer: -
- LCD Module: Yes
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 64MHz
- GPIO Ports Number: 25
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: LCD/LED Driver;DMA;WDT;Ethernet protocol stack;LIN(Local Interconnect Network)
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 512KB
- Universal Serial Bus: Yes
- communication protocol: 以太网协议
- Operating Voltage Range: 1.7V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: -
- Package: QFN-33(5x5)
- Manufacturer: Nuvoton Tech
- Series: NuMicro M262
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M23
- Core Size: 32-Bit
- Speed: 64MHz
- Connectivity: EBI/EMI, Ethernet, I²C, LINbus, SCI, SmartCard, SPI, USB
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, LVR, POR, PWM, WDT
- Number of I/O: 25
- Program Memory Size: 512KB (512K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.7V ~ 3.6V
- Data Converters: A/D 9x12b SAR; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 32-WFQFN Exposed Pad
- Supplier Device Package: 33-QFN (5x5)
- detail: ARM® Cortex®-M23 NuMicro M262 Microcontroller IC 32-Bit 64MHz 512KB (512K x 8) FLASH 33-QFN (5x5)
