NSR0340P2T5G دیتاشیت

NSR0340P2T5G

مشخصات دیتاشیت

نام دیتاشیت NSR0340P2T5G
حجم فایل 75.29 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

مشاهده دیتاشیت NSR0340P2T5G

دانلود دیتاشیت

سایر مستندات

NSR0340P2T5G 4 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NSR0340P2T5G
  • Reverse Voltage (Vr): 40V
  • Forward Voltage (Vf@If): 560mV@200mA
  • Reverse Leakage Current (Ir): 20uA@40V
  • Average Rectified Current (Io): 200mA
  • Package: SOD-923
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 40V
  • Current - Average Rectified (Io): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 560mV @ 200mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Reverse Recovery Time (trr): 3ns
  • Current - Reverse Leakage @ Vr: 20µA @ 40V
  • Capacitance @ Vr, F: 4pF @ 5V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SOD-923
  • Supplier Device Package: SOD-923
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Base Part Number: NSR034
  • detail: Diode Schottky 40V 200mA (DC) Surface Mount SOD-923
