- دیتاشیت NCP114ASN300T1G
NCP114ASN300T1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NCP114ASN300T1G |
|---|---|
| حجم فایل | 846.05 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت NCP114ASN300T1G |
دانلود دیتاشیت |
|---|
سایر مستندات
NCP114 19 pages
NCP114AMX280TCG 18 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCP114ASN300T1G
- Output Type: Fixed
- Output Current: 300mA
- Output Voltage: 3V~3V
- Dropout Voltage: 245mV@(300mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Power Supply Rejection Ratio (PSRR): 75dB@(1kHz)
- Package: TSOP-5-1.5mm
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.245V @ 300mA
- Current - Output: 300mA
- Current - Quiescent (Iq): 95µA
- PSRR: 75dB (1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: SOT-23-5 Thin, TSOT-23-5
- Supplier Device Package: 5-TSOP
- Base Part Number: NCP114
- detail: Linear Voltage Regulator IC 1 Output 300mA 5-TSOP
