LM431SBCMFX دیتاشیت

LM431SBCMFX

مشخصات دیتاشیت

نام دیتاشیت LM431SBCMFX
حجم فایل 88.187 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت LM431SBCMFX

دانلود دیتاشیت

سایر مستندات

LM431SA, LM431SB, LM431SC 12 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: onsemi LM431SBCMFX
  • Tolerance: ±1%
  • Output Type: Adjustable
  • Input Voltage: -
  • Output Current: 100mA
  • Output Voltage: 2.495V~36V
  • Reference Type: parallel connection
  • Supply Current: -
  • Noise - 10Hz to 10kHz: -
  • Operating Temperature: -25°C~+85°C@(Ta)
  • Noise - 1/10Hz to 10Hz: -
  • Temperature Coefficient: 50ppm/°C
  • Minimum Cathode Current for Regulation: 1mA
  • Package: SOT-23(TO-236)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Output (Min/Fixed): 2.495V
  • Voltage - Output (Max): 36V
  • Current - Output: 100mA
  • Noise - 0.1Hz to 10Hz: -
  • Voltage - Input: -
  • Current - Supply: -
  • Current - Cathode: 1mA
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-3 Flat Leads
  • Supplier Device Package: SOT-23F-3
  • Base Part Number: LM431
  • detail: Shunt Voltage Reference IC 36V ±1% SOT-23F-3
