MMBF4093 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MMBF4093
|
|
حجم فایل
|
70.553
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/JFETs
-
FET Type:
N-Channel
-
Datasheet:
onsemi MMBF4093
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Input Capacitance (Ciss@Vds):
16pF@20V
-
Total Device Dissipation (Pd):
350mW
-
Drain Current (Idss@Vds,Vgs=0):
8mA@20V
-
Gate-Source Breakdown Voltage (V(BR)GSS):
40V
-
Gate-Source Cutoff Voltage (VGS(off)@ID):
1V@1nA
-
Static Drain-Source On Resistance (RDS(on)):
80Ω
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Breakdown (V(BR)GSS):
40V
-
Current - Drain (Idss) @ Vds (Vgs=0):
8mA @ 20V
-
Voltage - Cutoff (VGS off) @ Id:
1V @ 1nA
-
Input Capacitance (Ciss) (Max) @ Vds:
16pF @ 20V
-
Resistance - RDS(On):
80 Ohms
-
Power - Max:
350mW
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
MMBF40
-
detail:
JFET N-Channel 40V 350mW Surface Mount SOT-23-3
