S1BFL دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
S1BFL
|
|
حجم فایل
|
53.988
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Diodes - General Purpose
-
Datasheet:
onsemi S1BFL
-
Reverse Voltage (Vr):
100V
-
Forward Voltage (Vf@If):
1.1V@1A
-
Package:
SOD-123FL
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io):
1A
-
Voltage - Forward (Vf) (Max) @ If:
1.1V @ 1A
-
Speed:
Standard Recovery >500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
2µs
-
Current - Reverse Leakage @ Vr:
1µA @ 100V
-
Capacitance @ Vr, F:
4pF @ 4V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
SOD-123F
-
Supplier Device Package:
SOD-123F
-
Operating Temperature - Junction:
-50°C ~ 150°C
-
Base Part Number:
S1B
-
detail:
Diode Standard 100V 1A Surface Mount SOD-123F
