MC78L08ACDR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MC78L08ACDR2G
|
|
حجم فایل
|
89.285
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi MC78L08ACDR2G
-
Output Type:
Fixed
-
Output Current:
100mA
-
Output Voltage:
8V~8V
-
Dropout Voltage:
1.7V@(40mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
30V
-
Operating Temperature:
0°C~+125°C
-
Quiescent Current (Ground Current):
6mA
-
Power Supply Rejection Ratio (PSRR):
57dB@(120Hz)
-
Package:
SOIC-8
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
-
-
Current - Output:
100mA
-
Current - Quiescent (Iq):
6mA
-
PSRR:
57dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Temperature, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
MC78L08
-
detail:
Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
