- دیتاشیت NUP1105LT1G
NUP1105LT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NUP1105LT1G |
|---|---|
| حجم فایل | 78.291 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت NUP1105LT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
NUP1105LT1G, SZNUP1105LT1G 5 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Polarity: Bi-Directional
- Datasheet: onsemi NUP1105LT1G
- Number of Lines: 1
- Clamping Voltage@Ipp: 44V
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 25.7V
- Peak Pulse Power(Ppp)@8/20us: 350W
- Junction Capacitance(Cj)@1MHz: 60pF@1MHz
- Peak Pulse Current(Ipp)@8/20us: 8A
- Reverse Stand-Off Voltage (Vrwm): 24V
- Package: SOT-23(TO-236)
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 24V (Min)
- Voltage - Breakdown (Min): 25.7V
- Voltage - Clamping (Max) @ Ipp: 44V
- Current - Peak Pulse (10/1000µs): 8A (8/20µs)
- Power - Peak Pulse: 350W
- Power Line Protection: No
- Applications: Automotive
- Capacitance @ Frequency: 60pF @ 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Base Part Number: NUP1105
- detail: 44V Clamp 8A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
