دیتاشیت J113-D74Z

J111-13, MMBFJ111-13

مشخصات دیتاشیت

نام دیتاشیت J111-13, MMBFJ111-13
حجم فایل 424.329 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت J111-13, MMBFJ111-13

J111-13, MMBFJ111-13 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/JFETs
  • FET Type: N-Channel
  • Datasheet: onsemi J113-D74Z
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Input Capacitance (Ciss@Vds): -
  • Total Device Dissipation (Pd): 625mW
  • Drain Current (Idss@Vds,Vgs=0): 2mA@15V
  • Gate-Source Breakdown Voltage (V(BR)GSS): 35V
  • Gate-Source Cutoff Voltage (VGS(off)@ID): 500mV@1uA
  • Static Drain-Source On Resistance (RDS(on)): 100Ω
  • Package: TO-92-3
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Breakdown (V(BR)GSS): 35V
  • Current - Drain (Idss) @ Vds (Vgs=0): 2mA @ 15V
  • Voltage - Cutoff (VGS off) @ Id: 500mV @ 1µA
  • Input Capacitance (Ciss) (Max) @ Vds: -
  • Resistance - RDS(On): 100 Ohms
  • Power - Max: 625mW
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Supplier Device Package: TO-92-3
  • Base Part Number: J113
  • detail: JFET N-Channel 35V 625mW Through Hole TO-92-3
