- دیتاشیت SZESD8351HT1G
SZESD8351HT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SZESD8351HT1G |
|---|---|
| حجم فایل | 77.229 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت SZESD8351HT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
ESD8351, SZESD8351 9 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: onsemi SZESD8351HT1G
- Number of Lines: 1
- Clamping Voltage@Ipp: 5.5V
- Operating Temperature: -55°C~+125°C@(Tj)
- Breakdown Voltage (VBR): 5.5V
- Junction Capacitance(Cj)@1MHz: 0.4pF@1MHz
- Peak Pulse Current(Ipp)@8/20us: 5A@(8/20us)
- Reverse Stand-Off Voltage (Vrwm): 3.3V
- Package: SOD-323
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 3.3V (Max)
- Voltage - Breakdown (Min): 5.5V
- Voltage - Clamping (Max) @ Ipp: 11.2V
- Current - Peak Pulse (10/1000µs): 5A (8/20µs)
- Power - Peak Pulse: -
- Power Line Protection: No
- Applications: Automotive
- Capacitance @ Frequency: 0.37pF @ 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-76, SOD-323
- Supplier Device Package: SOD-323
- Base Part Number: SZESD8
- detail: 11.2V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SOD-323
