دیتاشیت BC63916-D27Z
مشخصات دیتاشیت
| نام دیتاشیت |
BC63916-D27Z
|
| حجم فایل |
66.489
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi BC63916-D27Z
-
Transistor Type:
NPN
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Collector Current (Ic):
1A
-
Power Dissipation (Pd):
1W
-
Transition Frequency (fT):
100MHz
-
DC Current Gain (hFE@Ic,Vce):
100@150mA,2V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
80V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
500mV@500mA,50mA
-
Package:
TO-92-3
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Current - Collector (Ic) (Max):
1A
-
Voltage - Collector Emitter Breakdown (Max):
80V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 50mA, 500mA
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
40 @ 150mA, 2V
-
Power - Max:
625mW
-
Frequency - Transition:
200MHz
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
BC639
-
detail:
Bipolar (BJT) Transistor NPN 80V 1A 200MHz 625mW Through Hole TO-92-3
