دیتاشیت NUC230LC2AE

NUC230, 240 Datasheet

مشخصات دیتاشیت

نام دیتاشیت NUC230, 240 Datasheet
حجم فایل 3031.349 کیلوبایت
نوع فایل pdf
تعداد صفحات 97

دانلود دیتاشیت NUC230, 240 Datasheet

NUC230, 240 Datasheet Datasheet

مشخصات

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM Cortex-M0
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 8KB
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 72MHz
  • GPIO Ports Number: 35
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: DMA;WDT;Low-VoltageDetect;LIN(Local Interconnect Network);IrDA
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 32KB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 2.5V~5.5V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+105°C
  • Secure Digital Input and Output: -
  • Package: LQFP-48(7x7)
  • Manufacturer: Nuvoton Tech
  • Series: NuMicro™ NUC230
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: ARM® Cortex®-M0
  • Core Size: 32-Bit
  • Speed: 72MHz
  • Connectivity: CANbus, I²C, IrDA, LINbus, SmartCard, SPI, UART/USART
  • Peripherals: Brown-out Detect/Reset, DMA, I²S, LVD, POR, PS2, PWM, WDT
  • Number of I/O: 35
  • Program Memory Size: 32KB (32K x 8)
  • EEPROM Size: 4K x 8
  • Voltage - Supply (Vcc/Vdd): 2.5V ~ 5.5V
  • Data Converters: A/D 7x12b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 48-LQFP
  • Supplier Device Package: 48-LQFP (7x7)
  • detail: ARM® Cortex®-M0 NuMicro™ NUC230 Microcontroller IC 32-Bit 72MHz 32KB (32K x 8) FLASH 48-LQFP (7x7)
