MUR120 Series دیتاشیت

MUR120 Series

مشخصات دیتاشیت

نام دیتاشیت MUR120 Series
حجم فایل 118.739 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت MUR120 Series

دانلود دیتاشیت

سایر مستندات

MUR120RLG 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: onsemi MUR160RLG
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 600V
  • Operating Temperature: -65°C~+175°C@(Tj)
  • Forward Voltage (Vf@If): 1.25V@1A
  • Reverse Leakage Current: 5uA@600V
  • Reverse Recovery Time (trr): 75ns
  • Average Rectified Current (Io): 1A
  • Package: DO-41
  • Manufacturer: onsemi
  • Series: SWITCHMODE™
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 1.25V @ 1A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 5µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: DO-204AL, DO-41, Axial
  • Supplier Device Package: Axial
  • Operating Temperature - Junction: -65°C ~ 175°C
  • Base Part Number: MUR16
  • detail: Diode Standard 600V 1A Through Hole Axial
