دیتاشیت 2SC5488A-TL-H
مشخصات دیتاشیت
| نام دیتاشیت |
2SC5488A
|
| حجم فایل |
466.876
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi 2SC5488A-TL-H
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
70mA
-
Power Dissipation (Pd):
100mW
-
Transition Frequency (fT):
7GHz
-
DC Current Gain (hFE@Ic,Vce):
90@20mA,5V
-
Collector Cut-Off Current (Icbo):
1uA
-
Collector-Emitter Breakdown Voltage (Vceo):
10V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
-
-
Package:
SC-81
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Collector Emitter Breakdown (Max):
10V
-
Frequency - Transition:
7GHz
-
Noise Figure (dB Typ @ f):
1dB @ 1GHz
-
Gain:
12dB
-
Power - Max:
100mW
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
90 @ 20mA, 5V
-
Current - Collector (Ic) (Max):
70mA
-
Mounting Type:
Surface Mount
-
Package / Case:
3-SMD, Flat Lead
-
Supplier Device Package:
3-SSFP
-
Base Part Number:
2SC5488
-
detail:
RF Transistor NPN 10V 70mA 7GHz 100mW Surface Mount 3-SSFP
