SL24T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SL24T1G
|
|
حجم فایل
|
86.285
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
onsemi SL24T1G
-
Number of Lines:
1
-
Clamping Voltage@Ipp:
55V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Breakdown Voltage (VBR):
26.7V
-
Peak Pulse Power(Ppp)@8/20us:
300W
-
Junction Capacitance(Cj)@1MHz:
3.5pF@1MHz
-
Reverse Stand-Off Voltage (Vrwm):
24V
-
Package:
SOT-23-3
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Unidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
24V
-
Voltage - Breakdown (Min):
26.7V
-
Voltage - Clamping (Max) @ Ipp:
55V
-
Current - Peak Pulse (10/1000µs):
5A (8/20µs)
-
Power - Peak Pulse:
300W
-
Power Line Protection:
No
-
Applications:
Automotive
-
Capacitance @ Frequency:
3.5pF @ 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
SL24
-
detail:
55V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
