دیتاشیت MC74HC125ADR2G

مشخصات دیتاشیت

دانلود دیتاشیت MC74HC125A, MC74HC126A	MC74HC125A, MC74HC126A Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: onsemi MC74HC125ADR2G
output type: Tri-State
Logic Family: 74HC
Sink Current: 7.8mA
Source Current: 7.8mA
Supply Voltage: 2V~6V
Number of Elements: 4
Operating Temperature: -55°C~+125°C
Number of Bits per Element: 1
Package: SOP-14
Manufacturer: onsemi
Series: 74HC
Packaging: Cut Tape (CT)
Part Status: Active
Logic Type: Buffer, Non-Inverting
Input Type: -
Current - Output High, Low: 7.8mA, 7.8mA
Voltage - Supply: 2V ~ 6V
Mounting Type: Surface Mount
Package / Case: 14-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 14-SOIC
Base Part Number: MC74HC125
detail: Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-SOIC
