LM124, 224x, 324x 数据手册
其他文档
LM2902DR2G 17 pages
技术规格
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: onsemi LM324ADR2G
- -3db Bandwidth: -
- Output Current: 40mA
- Number of Circuits: 4
- Operating Temperature: 0°C~+70°C
- Current - Input Bias(Ib): 40nA
- Gain Bandwidth Product(GBP): 1MHz
- Package: SOP-14
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Amplifier Type: General Purpose
- Output Type: -
- Slew Rate: 0.4V/µs
- Gain Bandwidth Product: 1.3MHz
- Current - Input Bias: 20nA
- Voltage - Input Offset: 2mV
- Current - Supply: 1.5mA
- Current - Output / Channel: 70mA
- Voltage - Supply, Single/Dual (±): 3V ~ 30V, ±1.5V ~ 15V
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 14-SO
- Base Part Number: LM324
- detail: General Purpose Amplifier 4 Circuit 14-SO
