SZESD7205WTT1G دیتاشیت

SZESD7205WTT1G

مشخصات دیتاشیت

نام دیتاشیت SZESD7205WTT1G
حجم فایل 85.259 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

مشاهده دیتاشیت SZESD7205WTT1G

دانلود دیتاشیت

سایر مستندات

ESD7205, SZESD7205 8 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SZESD7205WTT1G
  • Clamping Voltage@Ipp: 12.5V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Breakdown Voltage (VBR): 5.2V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: 0.4pF@1MHz
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Package: SOT-323(SC-70)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 2
  • Voltage - Reverse Standoff (Typ): 5V (Max)
  • Voltage - Breakdown (Min): 5.2V
  • Voltage - Clamping (Max) @ Ipp: 12.5V (Typ)
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: Ethernet
  • Capacitance @ Frequency: 0.47pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SC-70-3 (SOT323)
  • Base Part Number: ESD72
  • detail: 12.5V (Typ) Clamp Ipp Tvs Diode Surface Mount SC-70-3 (SOT323)
