NL7WB66USG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NL7WB66USG
|
|
حجم فایل
|
82.943
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
onsemi NL7WB66USG
-
Turn-on time:
3.9ns
-
Turn-off time:
6.3ns
-
Supply Voltage:
1.65V~5.5V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
2
-
On-State Resistance (Max):
10Ω
-
Package:
US-8
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Number of Circuits:
2
-
Channel-to-Channel Matching (ΔRon):
15Ohm
-
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
-
Voltage - Supply, Dual (V±):
-
-
Switch Time (Ton, Toff) (Max):
3.9ns, 6.3ns
-
-3db Bandwidth:
186MHz
-
Charge Injection:
7.5pC
-
Channel Capacitance (CS(off), CD(off)):
10pF, 10pF
-
Current - Leakage (IS(off)) (Max):
1nA
-
Crosstalk:
-
-
Operating Temperature:
-55°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-VFSOP (0.091", 2.30mm Width)
-
Supplier Device Package:
US8
-
Base Part Number:
NL7WB
-
detail:
2 Circuit IC Switch 1:1 10Ohm US8
