MC74HC238ADTR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MC74HC238ADTR2G
|
|
حجم فایل
|
71.957
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Type:
Decoder/Demultiplexers
-
Category:
Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
-
Datasheet:
onsemi MC74HC238ADTR2G
-
Sink Current:
5.2mA
-
Source Current:
5.2mA
-
Supply Voltage:
2V~6V
-
Operating temperature:
-55°C~+125°C
-
Voltage Supply Source:
Single supply
-
Package:
TSSOP-16-4.3mm
-
Manufacturer:
onsemi
-
Series:
74HC
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Circuit:
1 x 3:8
-
Independent Circuits:
1
-
Current - Output High, Low:
5.2mA, 5.2mA
-
Voltage - Supply:
2V ~ 6V
-
Mounting Type:
Surface Mount
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
16-TSSOP
-
Base Part Number:
MC74HC238
-
detail:
Decoder/Demultiplexer 1 x 3:8 16-TSSOP
