دیتاشیت NCP186BMX330TAG
مشخصات دیتاشیت
| نام دیتاشیت |
NCP186
|
| حجم فایل |
528.82
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP186BMX330TAG
-
Output Current:
1A
-
Output Voltage:
3.3V
-
Dropout Voltage:
0.145V@(1A)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
140uA
-
Power Supply Rejection Ratio (PSRR):
75dB@(1kHz)
-
Package:
DFN-8(1.2x1.6)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
3.3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.145V @ 1A
-
Current - Output:
1A
-
Current - Quiescent (Iq):
140µA
-
PSRR:
75dB (1kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Soft Start
-
Mounting Type:
Surface Mount
-
Package / Case:
8-XFDFN Exposed Pad
-
Supplier Device Package:
8-XDFN (1.6x1.2)
-
Base Part Number:
NCP186
-
detail:
Linear Voltage Regulator IC 1 Output 1A 8-XDFN (1.6x1.2)
