ES2A Datasheet
Datasheet specifications
|
Datasheet's name
|
ES2A
|
|
File size
|
458.934
KB
|
|
File type
|
pdf
|
|
Number of pages
|
4
|
Technical specifications
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
Shandong Jingdao Microelectronics ES2A
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
50V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1V@2A
-
Reverse Leakage Current:
5uA@50V
-
Reverse Recovery Time (trr):
35ns
-
Average Rectified Current (Io):
2A
-
Package:
SMA
-
Manufacturer:
Shandong Jingdao Microelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
50V
-
Current - Average Rectified (Io):
2A
-
Voltage - Forward (Vf) (Max) @ If:
900mV @ 2A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
10µA @ 50V
-
Capacitance @ Vr, F:
18pF @ 4V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
DO-214AA, SMB
-
Supplier Device Package:
DO-214AA (SMB)
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Base Part Number:
ES2
-
detail:
Diode Standard 50V 2A Surface Mount DO-214AA (SMB)
