دیتاشیت CPH3461-TL-W

CPH3461

مشخصات دیتاشیت

نام دیتاشیت CPH3461
حجم فایل 489.499 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت CPH3461

CPH3461 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 250V
  • Current - Continuous Drain (Id) @ 25°C: 350mA (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 2.5V, 4.5V
  • Rds On (Max) @ Id, Vgs: 6.5Ohm @ 170mA, 4.5V
  • Vgs(th) (Max) @ Id: 1.3V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 2.1nC @ 4.5V
  • Vgs (Max): ±10V
  • Input Capacitance (Ciss) (Max) @ Vds: 140pF @ 20V
  • FET Feature: -
  • Power Dissipation (Max): 1W (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 3-CPH
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Base Part Number: CPH346
  • detail: N-Channel 250V 350mA (Ta) 1W (Ta) Surface Mount 3-CPH
