LP2951ACNG Datasheet
Datasheet specifications
| Datasheet's name | LP2951ACNG |
|---|---|
| File size | 101.081 KB |
| File type | |
| Number of pages | 26 |
Download Datasheet LP2951ACNG |
Download Datasheet |
|---|
Other documentations
LP2950, LP2951, NCV2951 22 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi LP2951ACNG
- Output Type: -
- Package: PDIP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 30V
- Voltage - Output (Min/Fixed): 1.235V (5V)
- Voltage - Output (Max): 30V
- Voltage Dropout (Max): 0.45V @ 100mA
- Current - Output: 100mA
- Current - Quiescent (Iq): 120µA
- Current - Supply (Max): 12mA
- PSRR: -
- Control Features: -
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: LP295
- detail: Linear Voltage Regulator IC 1 Output 100mA 8-PDIP
