FDC637AN دیتاشیت

FDC637AN

مشخصات دیتاشیت

نام دیتاشیت FDC637AN
حجم فایل 74.407 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

مشاهده دیتاشیت FDC637AN

دانلود دیتاشیت

سایر مستندات

FDC637AN 5 pages

مشخصات فنی

  • RoHS: true
  • Type: N Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FDC637AN
  • Power Dissipation (Pd): 1.6W
  • Drain Source Voltage (Vdss): 20V
  • Continuous Drain Current (Id): 6.2A
  • Gate Threshold Voltage (Vgs(th)@Id): 1.5V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 24mΩ@4.5V,6.2A
  • Package: SOT-666-6
  • Manufacturer: onsemi
  • Series: PowerTrench®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 20V
  • Current - Continuous Drain (Id) @ 25°C: 6.2A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 2.5V, 4.5V
  • Rds On (Max) @ Id, Vgs: 24mOhm @ 6.2A, 4.5V
  • Vgs(th) (Max) @ Id: 1.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 16nC @ 4.5V
  • Vgs (Max): ±8V
  • Input Capacitance (Ciss) (Max) @ Vds: 1125pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 1.6W (Ta)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SuperSOT™-6
  • Package / Case: SOT-23-6 Thin, TSOT-23-6
  • Base Part Number: FDC637
  • detail: N-Channel 20V 6.2A (Ta) 1.6W (Ta) Surface Mount SuperSOT™-6
