NCP606MN33T2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP606MN33T2G
|
|
حجم فایل
|
85.004
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP606MN33T2G
-
Output Type:
Fixed
-
Output Current:
500mA
-
Output Voltage:
3.3V
-
Dropout Voltage:
220mV@(500mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
6V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
180uA
-
Power Supply Rejection Ratio (PSRR):
-
-
Package:
DFN-6(3x3)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
6V
-
Voltage - Output (Min/Fixed):
3.3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.22V @ 500mA
-
Current - Output:
500mA
-
Current - Quiescent (Iq):
180µA
-
PSRR:
-
-
Control Features:
Enable
-
Protection Features:
Over Temperature, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
6-VDFN Exposed Pad
-
Supplier Device Package:
6-DFN (3x3)
-
Base Part Number:
NCP606
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 6-DFN (3x3)
