FDC3601N دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDC3601N	دانلود دیتاشیت

RoHS: true
Type: -
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi FDC3601N
Power Dissipation (Pd): -
Total Gate Charge (Qg@Vgs): -
Drain Source Voltage (Vdss): -
Input Capacitance (Ciss@Vds): -
Continuous Drain Current (Id): -
Gate Threshold Voltage (Vgs(th)@Id): -
Reverse Transfer Capacitance (Crss@Vds): -
Drain Source On Resistance (RDS(on)@Vgs,Id): -
Package: SSOT-6
Manufacturer: onsemi
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 N-Channel (Dual)
FET Feature: Standard
Drain to Source Voltage (Vdss): 100V
Current - Continuous Drain (Id) @ 25°C: 1A
Rds On (Max) @ Id, Vgs: 500mOhm @ 1A, 10V
Vgs(th) (Max) @ Id: 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 5nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 153pF @ 50V
Power - Max: 700mW
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: SOT-23-6 Thin, TSOT-23-6
Supplier Device Package: SuperSOT™-6
Base Part Number: FDC3601
detail: Mosfet Array 2 N-Channel (Dual) 100V 1A 700mW Surface Mount SuperSOT™-6
