- دیتاشیت MC74AC74DR2G
MC74AC74DR2G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC74AC74DR2G |
|---|---|
| حجم فایل | 77.008 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت MC74AC74DR2G |
دانلود دیتاشیت |
|---|
سایر مستندات
MC74AC74, MC74ACT74 10 pages
مشخصات فنی
- RoHS: true
- Type: D-Type
- Series: 74AC
- Category: Logic ICs/Flip Flops
- Function: 置位和复位
- Datasheet: onsemi MC74AC74DR2G
- Output Type: 互补型
- Sink Current: 24mA
- Trigger Type: 上升沿
- Source Current: 24mA
- Supply Voltage: 2V~6V
- Clock Frequency: 160MHz
- Input Capacitance: 4.5pF
- Number of Channels: 1
- Operating Temperature: -40°C~+85°C
- Quiescent Current (Iq): 4uA
- Maximum Propagation Delay: 10ns@5V,50pF
- Package: SOIC-14
- Manufacturer: onsemi
- Packaging: Cut Tape (CT)
- Part Status: Active
- Number of Elements: 2
- Number of Bits per Element: 1
- Max Propagation Delay @ V, Max CL: 10ns @ 5V, 50pF
- Current - Output High, Low: 24mA, 24mA
- Voltage - Supply: 2V ~ 6V
- Current - Quiescent (Iq): 4µA
- Mounting Type: Surface Mount
- Supplier Device Package: 14-SOIC
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Base Part Number: MC74AC74
- detail: Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-SOIC (0.154", 3.90mm Width)
