NUP4102XV6T1G دیتاشیت

NUP4102XV6T1G

مشخصات دیتاشیت

نام دیتاشیت NUP4102XV6T1G
حجم فایل 89.885 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

مشاهده دیتاشیت NUP4102XV6T1G

دانلود دیتاشیت

سایر مستندات

NUP4102XV6 3 pages

NUP4102XV6T1G 3 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi NUP4102XV6T1G
  • Number of Lines: 4
  • Clamping Voltage@Ipp: 25V
  • Breakdown Voltage (VBR): 13.6V
  • Package: SOT-563
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Not For New Designs
  • Type: Zener
  • Bidirectional Channels: 4
  • Voltage - Reverse Standoff (Typ): 12V (Max)
  • Voltage - Breakdown (Min): 13.6V
  • Voltage - Clamping (Max) @ Ipp: 25V
  • Current - Peak Pulse (10/1000µs): 3A (8/20µs)
  • Power - Peak Pulse: 75W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 13pF @ 1MHz
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: SOT-563, SOT-666
  • Supplier Device Package: SOT-563
  • Base Part Number: NUP4102
  • detail: 25V Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount SOT-563
