NC7WZ08 دیتاشیت

NC7WZ08

مشخصات دیتاشیت

نام دیتاشیت NC7WZ08
حجم فایل 518.834 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

مشاهده دیتاشیت NC7WZ08

دانلود دیتاشیت

سایر مستندات

NC7WZ08L8X 9 pages

مشخصات فنی

  • RoHS: true
  • Series: 7WZ
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NC7WZ08L8X
  • Sink Current: 32mA
  • Source Current: 32mA
  • Supply Voltage: 1.65V~5.5V
  • Logic Gate Type: And
  • Number of Channels: 2
  • Operating Temperature: -40°C~+85°C
  • Propagation Delay Time: 3.7ns@5V,50pF
  • Quiescent Current (Max): 1uA
  • Package: MicroPak-8
  • Manufacturer: onsemi
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: AND Gate
  • Number of Circuits: 2
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 1.65V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 32mA, 32mA
  • Logic Level - Low: -
  • Logic Level - High: -
  • Max Propagation Delay @ V, Max CL: 3.7ns @ 5V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-MicroPak™
  • Package / Case: 8-UFQFN
  • Base Part Number: NC7WZ0
  • detail: AND Gate IC 2 Channel 8-MicroPak™
