NTHD3102CT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NTHD3102C	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: N and P-Channel
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 20V
Current - Continuous Drain (Id) @ 25°C: 4A, 3.1A
Rds On (Max) @ Id, Vgs: 45mOhm @ 4.4A, 4.5V
Vgs(th) (Max) @ Id: 1.2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 7.9nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds: 510pF @ 10V
Power - Max: 1.1W
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 8-SMD, Flat Lead
Supplier Device Package: ChipFET™
Base Part Number: NTHD31
detail: Mosfet Array N and P-Channel 20V 4A, 3.1A 1.1W Surface Mount ChipFET™
